API Forged Steel Check Valve

API Forged Steel Check Valve

Short Description:

winocean is API Forged Steel Check Valve manufacturer in china ,...


  • Material : Forged Steel
  • Standards: API
  • Pressure: 150~2500lbs

Product Details

Product Tags

API  Forged Steel Check Valve


Technical Data:

Standard Nominal Pressure Nominal Diameter Applicable Medium
H41.PH41 150~2500LBS 1/2”~2” Sea Water.Fresh Water

Material of Main Parts:
Item Parts Name Material Code
1 Body Forged Steel A105N/F22
2 Disc Stainless Steel F430/F304
3 Stem Stainless Steel F6A
4 Bonnet Forged Steel A105N/F22
5 Handwheel Carbon Steel WCB

Main Data：
Size L H
150~600 900~1500 2500
150 300 600 900~1500 2500 RP FP
1/2” 105 152 165 216 264 61 61 117 117
3/4” 117 178 190 229 273 61 78 117 117
1” 127 203 216 254 308 78 84 117 117
1-1/4” 140 216 229 279 349 84 103 152 152
1-1/2” 165 229 241 305 384 103 118 152 152
2” 203 267 292 368 451 118 130 195 195
